Description
energy-efficient hot water for residential use. This Smart Heat Pump System for Hot Water Supply leverages the advanced R290 refrigerant, known for Compact Heat Pump Water Heater low environmental impact and
high efficiency, making it an ideal choice for eco-conscious households.
The system's compact design allows for easy installation in homes with limited space, without compromising on performance. Despite Innovative Heat Pump for Rapid Water Heating size, the 300L capacity ensures a
continuous and ample supply of hot water, meeting the demands of even larger families. Whether you're taking a shower, washing dishes, or doing laundry, this Domestic Hot Water System guarantees consistent and
reliable hot water availability.
One of the standout features of this system is its energy-saving capabilities. By utilizing air source heat pump technology, the system efficiently converts ambient air into heat, significantly reducing electricity
consumption compared to traditional water heaters. This energy-saving hot water heat pump system not only lowers utility bills but also contributes to a greener environment by reducing carbon emissions.
The innovative heat pump technology integrated into this system ensures rapid water heating, delivering hot water faster than conventional methods. The smart design of the heat pump allows it to operate
effectively in various climates, making it a versatile solution for homeowners across different regions.
parameter
| KFXR-032BI-300L | |||
| Rated voltage | 220V~240/1N 50HZ | Brand | Panasonic |
| Rated frequency | 50Hz | Refrigerant | R290 |
| Heating capacity | 1500W | Maximum input power | 3100W |
| Heat pump rated power | 385W | Rated power of electric heating tube | 2500W |
| COP | 3.9 | Rated water pressure | 0.8MPa |
| Heating capacity | 32L/h | Suction/exhaust maximum working pressure | 1.0/3.0MPa |
| Rated maximum water temperature | 75℃ | Allowable working pressure on low/high pressure side | 1.0/3.0MPa |
| Working environment temperature | -7~45℃ | Maximum working pressure of heat exchanger | 3.0MPa |
| Rated capacity | 200L | Sound pressure level at 1 meter | 42 dB(A) |
| G.W. | 129KG | Packing Dimension (W×D×H) | 700×700×1950mm |
Details
High Efficiency A+++ Energy Level
Targeting the European market, 3VF+ Series Air to Water Heat Pump is specially developed with the most cutting-edge heat pump technology and modern design to meet stringent requirements for efficiency,
stability and quietness. Not only does 3VF+ series use R32 Refrigerant and full DC Inverter EVI technology, but also be rated with A+++ energy label. With top energyrating A+++ , the unit is currently most energy
efficient and can greatly reduce energy bills for customers.
High Efficiency Full DC Inverter Compressor
Adopt DC inverter compressor and DC brushless fan motor, which can realize 20%-120% stepless capacity adjustment. During operation, the speed of the compressor and fan can be automatically and intelligently
adjusted according to the actual load demand of the user, so as to reduce the energy consumption of the compressor and fan , so that the unit operates at the optimal level and achieves the energy saving purpose of
on-demand output.
