Description
The 7kW Cooling-only Swimming Pool Heat Pump is an energy-efficient solution designed to reduce swimming pool water temperature and maintain a comfortable swimming environment during hot weather. With a
rated cooling capacity of 7kW, this pool cooling heat pump efficiently removes excess heat from pool water and releases it into the surrounding environment. It is suitable for residential swimming pools, above ground
pools, villa pools, and other recreational pool applications requiring reliable and efficient cooling.
The 7kW Cooling-only Swimming Pool Heat Pump is specifically developed for swimming pool cooling applications. Unlike conventional pool heaters that increase water temperature, this cooling-only unit is designed
to continuously remove heat from the pool water, helping prevent overheating during hot summer weather.Its compact design makes it suitable for installations where space is limited, while the efficient heat pump
system provides stable cooling performance with relatively low energy consumption. This makes it an ideal swimming pool cooling system for residential and recreational applications.
Using advanced heat pump technology, the unit absorbs excess thermal energy from swimming pool water and transfers it to the ambient air. This process provides an efficient way to lower and maintain pool water
temperature without relying on conventional mechanical cooling systems.The pool cooling heat pump operates efficiently while providing continuous temperature control. By using electricity to drive the heat transfer
process rather than directly generating cooling, the system can provide an energy-efficient alternative for maintaining comfortable pool temperatures in warm climates.
Designed for convenient system integration, the 7kW Cooling-only Swimming Pool Heat Pump features a compact structure that helps simplify installation. It can be connected to the existing swimming pool water
circulation system, allowing pool water to pass through the heat exchanger for efficient cooling.The practical design also makes routine operation and maintenance easier. Regular cleaning of the unit and inspection of
the water circulation system can help maintain efficient cooling performance and extend the service life of the swimming pool cooling heat pump.
Parameter
| BFXKC-007SPRI | |||
| Power supply | 220V/1N~50/60Hz | Brand | Panasonic |
| Rated cooling capacity | 7.0kW | Max. refrigerant pressure | 4.2MPa |
| Rated heating input power | 2.83kW | Circulating cooling water flow | 1.3m3/h |
| Max. input current | 17A | Water side pressure drop | ≤30kPa |
| Refrigerant | R32 | Protection grade | IPX4 |
| Water pump external head | 3.5m | Noise | 58dB(A) |
| N.W. | 60KG | G.W. | 70KG |
DetailsAIROSD Swimming Pool Heat pump
Applicable to swimming pool, SPA or fish cultivation. Can be used for household & commercial.OEM design optional. Different color available.CE approved.
Small water temp difference only 1-5 deg c.
Both water heating & cooling, Min 8°C/ Max 40°C.Auto flow detect.
World famous Japanese brand compressor
Special materials are selected for special parts, and the characteristics of low wear, low energy consumption, high efficiency and durability are still maintained during long-term operation.
